1. Intro
Stainless Steel Wire Rope 8×7+1×19 is a stainless steel wire rope designed for stable performance, flexibility, and corrosion resistance. It is commonly used in lifting, hoisting, marine, and industrial applications requiring reliable operation.
2. Product Image
3. Features
Stable and flexible construction
Good corrosion resistance
Smooth operating performance
Suitable for industrial and marine applications
Reliable performance for lifting applications
4. Material / Construction / Diameter Range
| SUS304 | 8×7 + 1×19 | 1.20 ~ 1.50 |
| SUS316 | 8×7 + 1×19 | 1.20 ~ 1.50 |
5. Applications
Lifting and hoisting applications
Crane and winch systems
Marine and offshore applications
General industrial applications
Surface Finish
Bright finish
PVC / PA coated available upon request
6. Technical Specification
| Size (mm) |
Min. Breaking Load (Kgf) |
|
| 304 | 316 | |
| 1,20 | 140 | 96 |
| 1,50 | 175 | 120 |
7. Packaging
Standard packaging: wooden spool. Other packaging options available upon customer request.
8. Quality Control
All products are inspected throughout the production process, including:
Diameter inspection
Tensile strength testing
Breaking load testing
Visual and tactile surface inspection
Packaging verification
Customization
Customized specifications and packaging are available according to customer requirements.
